Rising Stem Cast Iron Gate Valve

Rising Stem Cast Iron Gate Valve

Body: Cast Iron

Seat Ring: Bronze

Wedge Face Ring: Bronze

Wedge: Cast Iron

Stem: Brass

Body Gasket: Graphite

Bolts: Steel

Nuts: Steel

Bonnet: Cast Iron

Back Seat Bushing: Brass

Packing: Graphite

Packing Gland: Brass

Gland Follower Bolts: Steel

Gland Follower Nuts: Steel

Gland Follower: Ductile Iron

Yoke Bushing: Brass

Yoke Bushing Nut: Bronze

Screw: Steel

Handwheel: Cast Iron

Handwheel Nut: Ductile Iron

Yoke: Cast Iron

Nominal Diameter: DN50 to DN300

Nominal Pressure: Class150 to Class2500, PN10 to PN64

End Connection: Flanged, Socketweld, Buttweld

Dimension

PN16                                                         Unit: mm
