Pneumatic Cage Control Valve
Custom Enquiry
Description
Pneumatic Cage Control Valve
Body: WCB, WC6, CF8,CF8M
Lower Sleeve: Stainless Steel
Valve Plug: Stainless Steel
Upper Sleeve: Stainless Steel
Valve Rod: Stainless Steel
Gasket: Stainless Steel
Stud: Stainless Steel
Bonnet: WCB, WC6, CF8, CF8M
Spring: Stainless Steel
Stuffing: PTFE, Soft Graphite
Dimensions
|
DN(mm) |
L |
H1 |
H3 |
H4 |
H5 |
Actuator | |||||||
| PN16
Class 150 |
PN64,
Class 300 |
PN100
Class 600 |
A | B | C | H2 | H6 | H7 | |||||
| 20 | 184 | 194 | 206 | 130 | 254 | 337 | 44 | 282 | 260 | 220 | 258 | 180 | 465 |
| 25 | 184 | 197 | 210 | 130 | 254 | 337 | 48 | 282 | 260 | 220 | 258 | 180 | 465 |
| 32 | 222 | 235 | 251 | 152 | 320 | 386 | 56 | 282 | 260 | 220 | 258 | 180 | 465 |
| 308 | 260 | 220 | 280 | 180 | 465 | ||||||||
| 40 | 222 | 235 | 251 | 152 | 320 | 402 | 65 | 282 | 260 | 220 | 258 | 180 | 465 |
| 308 | 260 | 220 | 280 | 180 | 465 | ||||||||
| 50 | 254 | 267 | 286 | 159 | 320 | 402 | 76 | 308 | 260 | 220 | 280 | 180 | 465 |
| 65 | 276 | 292 | 311 | 205 | 365 | 630 | 100 | 308 | 220 | 280 | 180 | 305 | 260 |
| 394 | 270 | 360 | 236 | 580 | 305 | ||||||||
| 80 | 298 | 317 | 337 | 205 | 365 | 630 | 100 | 308 | 220 | 280 | 180 | 305 | 260 |
| 394 | 270 | 360 | 236 | 580 | 305 | ||||||||
| 100 | 352 | 368 | 394 | 208 | 373 | 635 | 110 | 394 | 270 | 360 | 236 | 580 | 305 |
| 125 | 400 | 500 | 500 | 274 | 484 | 698 | 126 | 394 | 270 | 360 | 236 | 580 | 305 |
| 498 | 320 | 435 | 310 | 675 | 330 | ||||||||
| 150 | 451 | 473 | 508 | 333 | 529 | 705 | 149 | 394 | 270 | 360 | 236 | 580 | 305 |
| 498 | 320 | 435 | 310 | 675 | 330 | ||||||||
| 200 | 543 | 568 | 610 | 370 | 561 | 730 | 198 | 498 | 320 | 435 | 310 | 675 | 330 |
