Description
Jacketed Ball Valve
Body: WCB, SS304, SS316, CF8, CF8M
Bonnet: WCB, SS304, SS316, CF8, CF8M
Ball: WCB, SS304, SS316, CF8, CF8M
Stem: WCB, SS304, SS316, CF8, CF8M
Seat: WCB, SS304, SS316, CF8, CF8M
Packing: PTFE
Bolt: Stainless Steel
Nut: Carbon Steel, Stainless Steel
Lever: Carbon Steel
Nominal Diameter: DN15 to DN200
Nominal Pressure: PN16 to PN64, Class150 to Class1500
End Connection: Flanged
Dimension
PN16Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Unit: mm
| DN | L | D | D1 | D2 | D6 | b-f | Z-Ñ„d | W |
| 15 | 130 | 95 | 65 | 45 | 40 | 14-2 | 4-Ñ„14 | 115 |
| 20 | 140 | 105 | 75 | 55 | 51 | 14-2 | 4-Ñ„14 | 130 |
| 25 | 150 | 115 | 85 | 65 | 58 | 14-2 | 4-Ñ„14 | 150 |
| 32 | 165 | 135 | 100 | 78 | 66 | 16-2 | 4-Ñ„18 | 190 |
| 40 | 180 | 145 | 110 | 85 | 76 | 16-3 | 4-Ñ„18 | 230 |
| 50 | 200 | 160 | 125 | 100 | 88 | 16-3 | 4-Ñ„18 | 240 |
| 65 | 220 | 180 | 145 | 120 | 110 | 18-3 | 4-Ñ„18 | 280 |
| 80 | 250 | 195 | 160 | 135 | 121 | 20-3 | 8-Ñ„18 | 310 |
| 100 | 280 | 215 | 180 | 155 | 150 | 20-3 | 8-Ñ„18 | 330 |
| 125 | 320 | 245 | 210 | 185 | 176 | 22-3 | 8-Ñ„18 | 600 |
| 150 | 360 | 280 | 240 | 210 | 204 | 24-3 | 8-Ñ„23 | 800 |
| 200 | 400 | 335 | 295 | 265 | 260 | 26-3 | 12-Ñ„23 | 1000 |
