Eccentric Plug Valve
Body: Cast Iron, Ductile Iron, Carbon Steel
Bonnet: Cast Iron, Ductile Iron, Carbon Steel
Plug: Cast Iron, Ductile Iron, Carbon Steel
Seat: NBR, EPDM
Packing: Graphite, PTFE
Nominal Size: DN15 to DN350
Nominal Pressure: Class150 to Class300, PN10 to PN64
Dimensions
| Pressure | 150LB | |||||||||||||||
| Size | mm | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | 350 |
| in | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 | 2 1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 | |
| L-RF | 108 | 117 | 127 | 140 | 165 | 178 | 190 | 203 | 229 | 254 | 267 | 292 | 330 | 356 | 381 | |
| L-BW | 152 | 178 | 203 | 216 | 229 | 267 | 305 | 330 | 356 | 381 | 394 | 457 | 533 | 610 | 686 | |
| H | 59 | 63 | 75 | 95 | 107 | 142 | 152 | 178 | 252 | 272 | 342 | 398 | 495 | 580 | 625 | |
| W | 400 | 400 | 500 | 500 | 600 | 600 | 820 | 820 | 300 | 300 | 320 | 320 | 350 | 380 | 380 | |
| (kg) Weight | 10 | 12 | 14 | 17 | 19 | 21 | 29 | 33 | 48 | 75 | 98 | 125 | 171 | 230 | 370 | |
