Duplex Gate Valve
Body: Duplex Stainless Steel (A995 1B, A995 2A, A995 3A, A995 4A, A890 1C, A995 5A)
Disc: Duplex Stainless Steel (A995 1B, A995 2A, A995 3A, A995 4A, A890 1C, A995 5A)
Stem: Stainless Steel
Stem Nut: Brass
Bonnet: Stainless Steel
Nominal Size: DN40 to DN400
Nominal Pressure: PN10 to PN64, Class150 to Class1500
Dimensions
PN16Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Unit: mm
| DN | L | D | D1 | D2 | b | f |
| 40 | 165 | 150 | 110 | 88 | 19 | 3 |
| 50 | 178 | 165 | 125 | 100 | 19 | 3 |
| 65 | 190 | 185 | 145 | 120 | 19 | 3 |
| 80 | 203 | 200 | 160 | 135 | 19 | 3 |
| 100 | 229 | 220 | 180 | 156 | 19 | 3 |
| 125 | 254 | 250 | 210 | 186 | 19 | 3 |
| 150 | 267 | 285 | 240 | 212 | 19 | 3 |
| 200 | 292 | 340 | 295 | 268 | 20 | 3 |
| 250 | 330 | 405 | 355 | 318 | 22 | 3 |
| 300 | 356 | 460 | 410 | 373 | 24.5 | 3 |
| 400 | 406 | 580 | 525 | 433 | 28 | 4 |
